Kichler 16100CBR27 2700K 3.5-inch LED hardscape light

Product Description

The Kichler 16100CBR27 is a 3.5-inch integrated LED hardscape light in Centennial Brass, with 2700K light for retaining walls, masonry steps and outdoor kitchen edges. Its pivoting design lets the installer direct the light toward the intended surface; the available rotation depends on whether the mounting bracket is used.

Specifications

16100CBR27 specifications
Model 16100CBR27
Product type hardscape light
Finish Centennial Brass
Primary material Brass
Light source Integrated LED
Color temperature 2700K
Color rendering index 80 CRI
Input voltage 12V
Location rating Wet
UPC / GTIN-12 783927533317
Fixture length 3.5 in.
Delivered light output 10 lumens
Nominal power 0.3W
Operating voltage 9–15V AC
Mounting adjustment Up to 270° with bracket; up to 180° direct-mounted
Enclosure rating IP67
Surge protection 4,000V

Selection and installation planning

Select the 3.5-inch format to suit the available mounting space and the surface being lit. Check the manufacturer’s photometric and spacing diagrams at the planned mounting height before finalizing placement. Allow for bracket clearance and aim the light so the LED is not in a normal line of sight.

Use a compatible low-voltage landscape power supply—not a direct line-voltage connection. Have the installer calculate the circuit load and voltage drop for the actual cable length and conductor size, and confirm the manufacturer’s electrical requirements before wiring. Follow Kichler’s instructions for weather-resistant connections and mounting.

Manufacturer resources

Kichler 16100CBR27 product details · Manufacturer specification sheet · Installation instructions

Dimension drawing of the Kichler 16100CBR27 hardscape light, showing the short LED bar and mounting plate.
